What is Nickel Battery Tab?
This 3 mm wide, 0.09 mm thick nickel tab (99.99% Ni, 48 mm long) is the negative terminal for lithium polymer and pouch cells. It is welded to the copper anode current collector and carries current through the pouch seal, rated for up to 3 A.
Nickel Tab For Polymer Li-Ion Battery
| Material | Nickel 99.99% |
| Length | 48mm |
| Width | 3mm |
| Thickness | 0.09mm |
| Application | Connect to anode current collector as polymer battery negative terminal |
| Net Weight | 128mg/pcs |
| Max. Loading Current | 3A |
Applications
- Negative tabs for pouch and polymer cells
- Cell prototyping and repair
- Battery pack connections
Frequently asked questions
Why is nickel used for the negative tab?
Nickel is stable at the anode potential, resists corrosion and welds well to copper foil.
Do you ship outside Canada?
Yes. NanoLithium ships from Canada to the USA, Europe, South Korea and customers worldwide. Lead time and freight are confirmed with your quote.
