Automated True Density Tester

L380 cm * W280 cm * H280cm

Net Weight﹤10kg

Technical parameters:

1. Principle: gas displacement method;

2. Test function: true density, true size, measured skeletal density, open porosity, obturator porosimetry;

3. Test Range: 0.0001 g/ml- – no upper limit;

4. Analysis station: one sample analysis station;

5. Sample cell volume:10ml, 100ml volume cells, you can choose it according to your samples tested;

6. Test accuracy≤ 0.03%;

7. Repeatability: ≤ ± 0.01%;

8. Test Resolution: 0.0001g / ml;

9. Pressure Accuracy: imported high-precision pressure sensors;

10. Test efficiency: one sample test average is about 3-5 minutes; the test times can be set automatically;

11. Sample types: powders, granules, blocks, foam, and other solid samples, and syrupy substance, non-volatile non-corrosive liquids, and other samples;

12. Test gas: helium or nitrogen;

13. Test temperature range: room temperature;

14. Control program: fully automated control, simple and easy application; set USB interface, easy to export data; intelligent self-test, check the sample cell sealing automatically, excluding human error;

15. Instrument Design: Integrated design, LCD touch screen control, and display systems, high-performance, high-quality, small footprint, equipped with computers, cost savings;

16. Power Requirements: AC 220V ± 20V, 50Hz, power 100W.
