About Lithium Battery Strapping Tape
Lithium Battery Strapping Tape is a battery material and cell component. NanoLithium supplies it for battery research, cell prototyping and production. Full specifications are shown below, and bulk or custom quantities can be quoted on request. We ship from Canada to the USA, Europe, South Korea and worldwide.
The Adhesive Tape for the Packing of Lithium Battery is made of PET film backing and single side coated with acrylic adhesive. It’s provided with high performance in electrical insulation and heat resistance, excellent adhesion, and can be easily peeled off without residue. The material is environmentally friendly and ROHS complied.
Used on parts of lithium battery and for adhesion, packing, wrapping, and holding purposes on battery assembling process.
| Backing | PET | PET | PET | PET |
| Adhesive | Acrylic | Acrylic | Acrylic | Acrylic |
| Total Thickness(mm) | 0.030 | 0.035 | 0.050 | 0.055 |
| Color | Clear/Black | Clear/Black | Dark Green/Blue/Yellow/Amber | Dark Green/Blue/
Yellow/Amber |
| Peel Adhesion
（N/25mm) |
1.5-2.5 | 2.5-3.5 | 6-8 | 6-8 |
| Tensile strength
（N/25mm) |
50 | 80 | 85 | 95 |
| Breakdown Voltage（KV） | 3.5 | 3.5 | 5 | 5 |
| Unwind Force | Light | Light | Medium | Light |
| Standard Width(mm) | Customized | |||
| Standard Length(Meter) | 100/200 | |||
