About 300*200mm Size Lithium-Ion Battery Aluminum Foil 16um
300*200mm Size Lithium-Ion Battery Aluminum Foil 16um is a current-collector and electrode-substrate material. NanoLithium supplies it for anode and cathode current collectors and electrode substrates. Full specifications are shown below, and bulk or custom quantities can be quoted on request. We ship from Canada to the USA, Europe, South Korea and worldwide.
Width:200mm Lenght: 300mm Thicness:16um Mode:T-A16-A4
| Aluminum foil application for lithium-ion battery cathode current collector | |
| Width | 300mm |
| Thickness | 16±1 um |
| Areal density | 42~46g/ m2 |
| With transverse surface density uniformity | ≤0.003 g/ 40×40 mm |
| The same volume of vertical surface density uniformity | ≤0.03 g/ 400×40 mm |
| High temperature oxidation resistance (200°C*30min) | No oxidation |
| Connect no | <2 |
| Chemistry content(Al) | >99.45% |
| Extensibility | <0.5% |
| Normal temperature Tensile strength
kgf /mm2 |
>180 |
| After 1200C baking 1h, Tensile strength kgf/mm2 | >160 |
